[MITgcm-support] KPPhbl output

[Juncheng Zhang]

Hi Dimitris,

Thank you so much,

I followed the examples, however, I get error as below, do you know why it happens?
(PID.TID 0000.0001) *** ERROR *** Some form of convection has been enabled


Kind Regards
Juncheng Zhang
PhD Student,
Earth, Atmospheric, and Planetary Physics

Department of Physics
University of Toronto
McLennan Physical Laboratories
60 St Gorge St
Toronto, Ontario, M5S 1A7

juncheng.zhang at mail.utoronto.ca<mailto:juncheng.zhang at mail.utoronto.ca>

[Pursue STEM]<https://www.physics.utoronto.ca/>


From: MITgcm-support <mitgcm-support-bounces at mitgcm.org> on behalf of Dimitris Menemenlis <dmenemenlis at gmail.com>
Date: Friday, 27 June 2025 at 19:45
To: MITgcm Support <mitgcm-support at mitgcm.org>
Subject: Re: [MITgcm-support] KPPhbl output
Hi Juncheng, there are examples how to do this in following verification experiments:

dmenemen at 169-231-25-98 MITgcm % cd verification
dmenemen at 169-231-25-98 verification % grep -i kpphbl */inp*/data*
lab_sea/input.natl_box/data.diagnostics:  fields(1:3,2)  = 'KPPhbl  ','KPPfrac ','MXLDEPTH',
lab_sea/input/data.diagnostics:  fields(1:2,3)  = 'MXLDEPTH','KPPhbl  ',
vermix/input.my82/data.diagnostics:#                      'THETA   ','PHIHYD  ','KPPdbsfc','KPPhbl  ','KPPRi   ',
vermix/input.opps/data.diagnostics:#                      'THETA   ','PHIHYD  ','KPPdbsfc','KPPhbl  ','KPPRi   ',
vermix/input.pp81/data.diagnostics:#                      'THETA   ','PHIHYD  ','KPPdbsfc','KPPhbl  ','KPPRi   ',
vermix/input/data.diagnostics:  fields(1:2,4)  = 'MXLDEPTH','KPPhbl  ',
vermix/input/data.diagnostics:#                      'THETA   ','PHIHYD  ','KPPdbsfc','KPPhbl  ','KPPRi   ',

Cheers, D.


On Jun 27, 2025, at 4:32 PM, Juncheng Zhang <juncheng.zhang at mail.utoronto.ca> wrote:

I am running an simulation based on MITgcm reentrant tutorial,
I am wondering how can I output the mixed layer depth  - KPPhbl
What files needed to be modified?
